Network: default-deny with per-sandbox allowlist

How crucible's per-sandbox networking works — default-deny egress with a hostname allowlist, enforced on the host kernel. The document is deliberately concrete about the implementation. For the higher-level "why network isolation?", see VISION.md.

In action: a sandbox created with --net-allow pypi.org resolves and reaches pypi.org over HTTPS, while every other host — e.g. example.com — is refused at the DNS proxy. The allowlist is the whole reachable surface. (Regenerate with vhs demo/network.tape.)

Design goals

1. Default-deny. A sandbox with no network config gets no NIC attached and zero egress reachability. This is the out-of-the-box experience.
2. Hostname allowlist override. A sandbox configured with network.enabled=true and an allowlist of hostname patterns can reach exactly those hostnames (A/AAAA records only) over any TCP/UDP port. Everything else — ICMP to arbitrary hosts, egress to IP literals, connections to ports on resolved IPs we didn't answer for — is dropped.
3. Enforcement on the host kernel. Policy is applied in the host's nftables and a host-side DNS proxy the guest is forced to use. The guest is untrusted — if user code escalates to root and tears down guest-side firewall rules, the host rules still block egress.
4. Per-sandbox isolation. Sandbox A cannot see, reach, or influence sandbox B's network traffic, even if both are allowlisted to overlapping destinations.
5. Clean lifecycle. Create → use → delete leaves no orphan namespaces, veth pairs, nftables tables, or DNS proxy state. Daemon-crash recovery wipes stale per-sandbox network state on startup.

Non-goals

These are deliberate exclusions, not oversights:

• IPv6. All allocation and rules are IPv4-only (deferred).
• CIDR-based allowlists (10.0.0.0/8). Hostname-only.
• Port allowlists (pypi.org:443). Any port to allowed IPs; ports aren't constrained.
• Protocol allowlists. TCP, UDP, ICMP all allowed to allowed IPs — no per-protocol filter.
• Egress rate limiting. No per-sandbox rate limit.
• Packet capture / traffic logging — a planned item (crucible sandbox tcpdump, see ROADMAP.md).
• Bring-your-own-DNS (a per-sandbox upstream resolver). All sandboxes share the same upstream.
• Policy files. Configuration is per-request JSON; a policy.yaml superset is planned.
• A separate DNS-proxy process. The proxy runs in-process in the daemon.

Architecture

Every sandbox routes DNS to one shared host-side proxy and egresses through one shared nftables table; the guest's source IP — unique because every sandbox owns its own /30 — is the key that maps a packet to its policy.

The DNS anycast IP. The daemon reserves 10.20.255.254 inside the subnet pool as a host-side address, bound to a crucible-dns dummy interface in the host root netns. Every sandbox gets a route 10.20.255.254/32 via <its own gateway>, so DNS queries traverse the veth into host root netns and land on the single shared listener. The source IP of the incoming packet — the guest's address — identifies the sandbox unambiguously, because every sandbox owns a unique /30. An O(1) sync.Map lookup maps source IP to that sandbox's policy.

Each sandbox gets:

• Its own network namespace on the host (crucible-<id>).
• A veth pair: one end (veth-<id>-h) stays in the host root netns; the other (veth-<id>-g) moves into the sandbox netns.
• A bridge inside the netns joining the guest's tap-<id> (Firecracker's NIC) to veth-<id>-g, so the guest and the host-side veth share one L2 segment.
• A /30 from the 10.20.0.0/16 pool. Within the block: the host-side veth holds the first usable address (the guest's gateway), the guest holds the second (e.g. gateway 10.20.0.13, guest 10.20.0.14 in block 10.20.0.12/30). DNS points at the shared anycast 10.20.255.254.

Three shared host-root-netns resources are allocated once at startup:

• The crucible-dns dummy interface, carrying the anycast IP 10.20.255.254/32 every sandbox routes DNS to.
• The DNS proxy, one UDP listener bound to 10.20.255.254:53 (miekg/dns for wire format). Policies keyed by guest source IP in a sync.Map — O(1) read path, no mutex on the hot path.
• A single nftables inet table named crucible, containing a per-sandbox set of allowed IPs and a per-sandbox chain of filter rules.

Per-sandbox setup (on Manager.Create)

Order matters — each step assumes the previous succeeded; a failure triggers rollback that unwinds in reverse.

1. Allocate a /30 from the pool. A bitmap in the network Manager; create is rejected if exhausted (cap ~16K concurrent sandboxes).
2. Create the network namespace — crucible-<sandbox-id>.
3. Create the veth pair and move veth-<id>-g into the sandbox netns.
4. Assign IPs and bring links up — host-side veth gets the gateway address; the guest side is configured via DHCP (below).
5. Create the tap-<id> inside the sandbox netns for Firecracker to attach to.
6. Bridge inside the netns. A bridge joins veth-<id>-g and tap-<id> so the guest (on the tap) and the host-side veth (.1 of the /30, the gateway) sit on the same L2 segment. The guest reaches the gateway and, through it, the DNS anycast and allowed egress.
7. Register in the nftables crucible table — an IP set sandbox-<id>-allowed (with per-entry timeouts) and a chain sandbox-<id>:
   • iifname "veth-<id>-h" ip daddr 10.20.255.254 udp dport 53 accept — DNS to the proxy.
   • iifname "veth-<id>-h" ip daddr @sandbox-<id>-allowed accept — allowed IPs.
   • iifname "veth-<id>-h" drop — everything else from this sandbox. The forward chain jumps to sandbox-<id> when the source matches the sandbox's subnet; a single shared postrouting masquerade rule on the egress interface NATs all sandboxes.
8. Register with the DNS proxy — proxy.Register(sandboxID, sourceIP, allowlist). Queries from that source IP are now filtered against the allowlist.
9. Tell jailer to use this netns — pass --netns /var/run/netns/crucible-<id> to the jailer argv; Firecracker joins the netns on exec.
10. Configure Firecracker's NIC — PUT /network-interfaces/eth0 with host_dev_name=tap-<id> and a generated guest MAC. The guest's IP/gateway/DNS are handed out over DHCP by a per-netns responder, so the rootfs needs no per-sandbox baking.

Guest IP configuration: per-netns DHCP + agent-driven refresh on fork

DHCP client in the guest: systemd-networkd. Modern Ubuntu/Debian ship systemd-networkd as the default DHCP client. The crucible rootfs ships a small netplan config at /etc/netplan/60-crucible-eth0.yaml that tells it to DHCP on eth0 — that's the entire guest-side setup. iproute2's ip (for the link-bounce at fork time) is always present.

Initial boot: systemd-networkd brings eth0 up, DISCOVERs, and the per-netns responder OFFERs → REQUEST → ACK, configuring eth0. The responder is hand-rolled (one MAC, one lease, short TTL); it enters the target netns via runtime.LockOSThread + unix.Setns(CLONE_NEWNET) before binding UDP/67, and answers for the sandbox's pre-assigned IP + gateway + DNS (10.20.255.254).

Fork resume: a snapshot captures the source's eth0 config (its IP, its gateway) — neither reachable from the fork's new netns. Without intervention the guest is "dark" until systemd-networkd's next renewal. crucible fixes this: crucible-agent exposes POST /network/refresh over vsock, which sandbox.Manager.Fork invokes immediately after resume. The agent:

1. ip link set eth0 down — the kernel flushes eth0's config.
2. ip link set eth0 up — systemd-networkd sees the link-up event and starts a fresh DHCP cycle (DISCOVER, not a renewal of the stale lease).
3. Polls net.InterfaceByName("eth0") for a non-link-local IPv4, bounded by the handler timeout — returning once the new address is configured.

This adds roughly one DHCP round-trip (~100–300 ms) to fork cost, invisible next to snapshot-restore overhead. If systemd-networkd REQUESTs the source's stale IP, the responder compares requested-vs-offered and NAKs, forcing a DISCOVER onto the correct address. If the agent is unreachable (VM still booting, vsock not ready), Manager.Fork logs a warning and moves on — the guest recovers on systemd-networkd's own renewal cycle.

Packet flow

The allowed path — a DNS lookup that populates the nftables set, then egress to the attested IP:

Walking the cases:

• Allowed DNS query. The guest queries 10.20.255.254:53. nftables matches dport 53 accept and forwards to the proxy. The proxy maps source IP → sandbox → allowlist; pypi.org matches, so it forwards to upstream, gets the A record, adds that IP to sandbox-<id>-allowed with a TTL from the DNS answer (clamped to a floor), and returns the response.
• Allowed HTTP request. The guest opens TCP to the resolved IP. nftables matches ip daddr @sandbox-<id>-allowed accept; the packet egresses with masquerade, and conntrack un-masquerades the return path.
• Denied destination. TCP to an IP nothing resolved to falls through to drop. The guest sees a connection timeout — no ICMP unreachable (silent, so probing for reachable hosts gets no signal).
• Denied DNS query. A lookup for a non-allowlisted name returns NXDOMAIN (not REFUSED — less clueful that a filter exists); the guest fails the lookup and never connects.
• IP literal. curl http://93.184.216.34 does no DNS lookup, so that IP was never added to the set — dropped. This is the point of the design: the allowlist pivots on DNS-attested IPs, so IP literals never work unless a hostname you resolved answered with that IP.

Allowlist syntax & matching

Grammar — two rules, case-insensitive:

• Exact match: pypi.org.
• Single-label wildcard: *.npmjs.org matches registry.npmjs.org and www.npmjs.org, but not a.b.npmjs.org or bare npmjs.org.

No regex, no CIDR, no port numbers.

Matching. A trie keyed by reversed DNS labels per sandbox's allowlist. registry.npmjs.org → look up org.npmjs.registry; match if a prefix ends in an exact entry or a single-label wildcard at the matching depth. O(labels) per query.

Corner cases.

• Bare * is rejected at config time (that's "all internet" and must be requested explicitly).
• Entries are lowercased; trailing dots stripped (pypi.org. → pypi.org).
• Wildcards only in the first label — *.foo.*.com is rejected.

API shape

POST /sandboxes
{
  "vcpus": 1,
  "memory_mib": 512,
  "network": {
    "enabled": true,
    "allowlist": ["pypi.org", "*.npmjs.org", "github.com", "objects.githubusercontent.com"]
  }
}

Field semantics.

• network absent → no network (equivalent to {"enabled": false}).
• network.enabled = false → no NIC attached; other network fields ignored.
• network.enabled = true with an absent/empty allowlist → 400. An explicit allowlist is required; "full internet" is not a supported config (default-deny ethos — it must be an explicit gesture).
• network.enabled = true with a populated allowlist → applied per this doc.

Response. The sandbox response carries a network substruct describing the applied policy:

{
  "id": "sbx_...",
  "network": {
    "enabled": true,
    "allowlist": ["..."],
    "guest_ip": "10.20.0.14",
    "gateway": "10.20.0.13"
  }
}

Lifecycle integration

Where networking plugs into the sandbox lifecycle:

• Manager.Create — after jailer.Stage, before running jailer: allocate the subnet, set up netns/veth/bridge/tap/nftables, register with the DNS proxy, and pass the netns path to the runner.
• Manager.Delete — after the VM handle shuts down (chroot + cgroup cleanup): tear down the nftables chain/set, deregister from the DNS proxy, and delete the netns (which removes the veth pair). Best-effort and idempotent.
• Manager.Snapshot — network state is host-side, so snapshots don't capture it. No changes required.
• Manager.Fork — each fork gets its own subnet/netns/veth and inherits the source's allowlist. The fork's DHCP responder hands it a new IP; because the restored guest kernel holds the source's stale eth0 config, the daemon calls the agent's /network/refresh to bounce the link and re-DHCP onto the correct address (see above).
• Daemon startup (orphan reap) — list every crucible-* netns and every chain in the crucible nft table left by a prior run and wipe them, mirroring the jailer orphan reap.

Failure modes

Testing

• Unit (internal/network/allowlist.go tests): trie construction, wildcard matching, reject-bad-input, normalization.
• Unit (internal/network/subnet.go / bitmap.go tests): the allocator hands out unique /30s, releases them on delete, and rejects exhaustion.
• Unit (internal/network/dnsproxy tests): an in-process upstream stub exercises allowed / denied / NXDOMAIN-on-no-match / set-update-on-allowed cases.
• End-to-end (smoke_e2e.sh): default-deny, allowlisted (allowed / denied / IP-literal / *.domain), and per-fork networking against a live daemon.

Package layout

internal/network/
  doc.go              package doc
  manager.go          owns the subnet pool + DNS proxy; wires to sandbox.Manager; orphan reap
  subnet.go           /30 pool
  bitmap.go           allocation bitmap
  netns.go            netns create/delete (shells out to `ip netns`)
  veth.go             veth pair + bridge + tap setup inside the netns
  nft.go              nftables rule emission via `nft -f -`
  allowlist.go        trie + pattern matching
  exec.go             namespaced command execution helpers
  reap.go             startup orphan reap (netns + nft)
  dhcp/               per-netns DHCP responder (responder.go, wire.go)
  dnsproxy/           UDP DNS proxy + upstream forwarding (proxy.go, upstream.go)

Dependencies

• golang.org/x/sys/unix — netns entry (Setns) and syscall work.
• github.com/miekg/dns — DNS wire format + the upstream client. Chosen over rolling our own after weighing EDNS0, TCP fallback, and CNAME-chain walking against the RFC-1035 machinery it would require; it's used by CoreDNS and ExternalDNS and pulls only golang.org/x/net.
• DHCP is hand-rolled — the protocol is narrow (one MAC, one lease, two request types) and stable; the responder is ~260 LOC with no library pulled in.
• No netlink library — namespace/link/nftables manipulation shells out to ip and nft. Readable and debuggable; subprocess latency is a non-issue at per-sandbox-create-once granularity.
